GMD 100 Disc Mower

KUHN GMD 100 Disc Mower

Mowers in the KUHN GMD 100 Mower series are adapted to small and medium farm operations that require high standards in terms of dependability and cutting quality. Their compact design makes them perfectly compatible with smaller hp tractors. They are equipped with the 100 series cutter bar and market leading equipment that gives them the strength necessary for mowing operations.

GMD 100 Series includes 3 models from 2.40 to 3.51 metres: GMD 240 (2.40 m), GMD 280 (2.80 m), and GMD 310 (3.10 m).

Features & Benefits

These machines produce a clean and even cut. The cutter bar is highly effective and robust.

  • Large diameter gearwheels made from high precision forged steel with 3 teeth on all modules engaged.
  • Safety breakaway mechanism causes the mower unit to slightly pivot backwards to significantly reduce impact.
  • Mow banks and terraces at a tilt angle of up to 35° and down to -25° depending on the model.


  240 280 310
Working width (m) 2.40 2.80 3.10
Number of disks 6 7 8
Average swath width (m) 1.70 2.00 2.40
Transport position – Curtain folding Vertical – hydraulic rearward pivot integrated Vertical – hydraulic rearward pivot integrated Vertical – hydraulic rearward pivot integrated
PTO speed (rpm) 540 540 540

See full specs on the KUHN website. Please note: some models may not be available in New Zealand.open_in_new
